SCT130 – Wall-Mounted Tripod Turnstile
Minimal Footprint | Streamlined Access | Designed for Tight Spaces
The SCT130 Wall-Mounted Tripod Turnstile is a space-optimized access control solution built for facilities where floor space is limited or must remain unobstructed. Mounted directly to a vertical surface, it provides controlled, one-person-at-a-time passage while maintaining a clean, minimal presence—ideal for indoor environments such as staff entrances, gyms, small office lobbies, and controlled hallways.
This model offers all the reliability of a full tripod mechanism in a compact wall-fixed housing, with support for manual or motorized operation, access control integration, and emergency features.
Key Features:
Wall-Mounted Design
Eliminates the need for floor supports, ideal for tight or narrow passageways and facilities seeking a low-profile security solution.
Durable Construction
Made from 1.2 mm AISI 304 stainless steel, offering strong resistance to wear, corrosion, and daily use. Optional finishes include powder coating or 316-grade stainless steel for high-humidity or coastal environments.
Bi-Directional Passage Control
Configurable for manual or motorized rotation, with programmable switching time and direction. An optional drop-arm mechanism ensures safety during emergencies.
Access Control Ready
Integrates seamlessly with card readers, biometric systems, or keypads, using standard dry contact or TTL signals, with optional RS232, RS485, or LAN control for remote configuration.
LED Indicators
Visual feedback provided through dual-color LED panels, clearly signaling passage authorization status.
Technical Specifications:
Model: SCT130
Mounting: Wall-mounted (no floor contact required)
Material: AISI 304 stainless steel (1.2 mm); optional 316 or powder-coated finishes
Arms: Ø38 mm aluminum with electrostatic powder coating
Ingress Protection: IP54 (optional IP56)
Operating Temperature: -15°C to +60°C (optional -50°C with heater)
Passage Width: 470–520 mm
Operation: Manual or motorized, bi-directional rotation
Power Supply: 110–220V AC, 50/60 Hz
Power Consumption: 24V DC; standby 12W / max 60W
Indicators: Bi-directional LED panels
Control System: TTL CMOS 5–48V, dry contact; optional RS232/RS485/LAN
Optional Features:
Drop-arm function
UPS battery backup
Remote control receiver
Outdoor protection kit
Compact, secure, and easy to install, the SCT130 wall-mounted turnstile offers a smart access control solution when space is at a premium. It’s the perfect blend of efficiency and reliability for secure, low-footprint environments.
Description
Wall-Mounted Tripod Turnstile – Compact, Secure, and Efficient Access Control
The Wall-Mounted Tripod Turnstile is a space-saving access control solution, perfect for tight entryways and areas with limited floor space. Engineered for indoor and outdoor use, it offers durable performance, efficient throughput, and seamless integration with modern access control systems.
Key Features & Benefits
✅ Space-Saving Wall-Mounted Design: Designed for compact installations, freeing up valuable floor space while maintaining secure entry control.
✅ Reliable and Durable Build: Crafted from high-quality materials, it ensures long-lasting performance in both indoor and outdoor environments.
✅ Fast and Efficient Entry: With a passing speed of up to 25 people per minute, it is ideal for high-traffic areas where smooth flow is essential.
✅ Weather-Resistant Construction: Rated IP54 and operational between -15°C and +60°C, ensuring consistent functionality in varying conditions.
✅ Versatile Power Compatibility: Operates on 110V – 240V AC 50/60 Hz or 24V DC, providing flexibility for different power setups.
✅ Seamless Access Control Integration: Fully compatible with all standard access control systems, ensuring efficient and secure authentication.
✅ Emergency & Remote Control Options: Available with optional remote control, button units, and stabilizing bottom plate for enhanced functionality.
✅ Perfect for Various Applications: Suitable for corporate offices, public transport hubs, stadiums, factories, and other controlled-access environments.
Compact yet highly effective, the Wall-Mounted Tripod Turnstile is an ideal solution for facilities looking to maximize space without compromising security.
